75W 24V DIM TRIAC Constant Voltage LED Driver
$ 70.00
- Product descriptionALCV075 LED DRIVER SERIES - ALCV075-024-65-DIM TRIAC DIMMABLE IP65 CONSTANT VOLTAGE LED DRIVER FEATURES • AC phase-cut dimming• Input range from 205VAC to 256VAC• Work with leading edge and trailing edge TRIAC dimmers• Fully potted suitable for dry and damp location applications• Protections: Over Current / Short Circuit /Over Voltage / Over Temperture• IP65 Rated• RoHS compliant APPLICATION • Can be used with 24V light sources for example, LED Strips (aLED KIDEFLEX)• Indoor or outdoor installationsIP Class IP65 Product informationTechnical Data Output Voltage Range 24VDCRipple & Noise (Max.) note.2 0.5Vp-pVoltage Tolerance ± 5%Dimming Range 5%~100%Rated Current 3.2ARated Power 76.8WEfficiency (Typ.) note.1 84%Set up Time (Max) 0.5S / 230VAC at full load Input Rated Voltage 220~240VACVoltage Range 205~256VACFrequency Range 50/60 HzAC Current (Max.) 0.9A at 230VACPower Factor > 0.45 at 230Vac with full load.Inrush Current (Typ.) Cold Start 60A at 230VACLeakage Current (Typ.) <1mA / 230VAC Protections Over Voltage 110 % - 130% Output voltage limiting, auto-recoveryOver Current 120% - 150% Constant current limiting, auto-recoveryOver Temperature 110°C - 125°C Temperature limiting, auto-recoveryShort Circuit Hiccup mode, recovers automatically after fault condition is removed Environment Operation Temp. -20°C ~ 45°C (Refer to output load derating curve)Operation Humidity 20% ~ 90% RH non-condensing.Storage Temp. -20 ~ 80°CStorage Humidity 10% ~ 90% RH NOTES 1. All parameters NOT specially mentioned are measured at 230V/50HZ AC input, rated load and 25°C ambient temperature.2. Ripple & Noise are measured at 20MHZ bandwidth oscilloscope and with 0.1uf & 47uf parallel capacitor at 100% duty output3. The power supply is considered a component which will be installed a final equipment. The final equipment must be re-confirmed that it still meets EMC directives. Dimenions Lenght 137,5mmWidth 47mmHeight 32mmWeight 355g Safety Safety Standards meet EN61347-1,EN61347-2-13Withstand Voltage I/P - O/P : 3.75K VACIsolation Resistance I/P-O/P : 100M ohms / 500VDC at 25°CEMC Standards note.3 meet EN55015,EN61000-4-2,3,4,5,6,8,11 ,EN61547 Lifetime MTBF 100K hours min. @Ta=25°C Shipping Product can be shipped with these shipping methods. PostNord MyPack Collect 8,00 € Delivery in 1-3 business days. Package will be kept for 7 days at the pickup point. PostNord MyPack Home Finland 19,00 € Door to door service, delivery in 2-6 business days. PostNord Finland Parcel (For companies) 12,00 € Delivery in 1-3 business days. Door to Door service for business addresses. Matkahuolto Lähellä-package 8,50 € Delivery usually in 2-5 business days. The package will be kept for 7 days in the pick up location. Posti Standard Delivery Finland 9,00 € Delivery in 2-5 business days. DSV Parcel service point 8,50 € Delivery in 2-5 business days. Pick Up from Warehouse 0,00 € Pick up from warehouse (Rajakivenkatu 8, 20740 Turku) between 9AM-3PM on weekdays (closed on weekends and on national holidays). Products are ready for pick up in 3 hours.
DRIVER 200W 24V
60W 12V IP67 Constant Voltage LED Driver
50W 24V CV Driver
25W 12V LED Driver IP67 with Wires
